Fitting MS-5ALHU-6
Fitting MS-5ALHU-6
Fitting MS-5ALHU-6

Fitting MS-5ALHU-6

  • Product code: MS-5ALHU-6
  • Trademark: SMC
  • Origin: Việt Nam
  • Status: New
Contact
23-12-2023
91 view

A miniature tube fitting.
[Features]
· Compact piping space.
· Rotates 360° around the stud as an axis, allowing it to be fixed at any angle.
· Can be used in corrosive environments.
· Compact piping space.
· RoHS compliant.
[Applications]
· As a soft tube fitting.

Configured Specifications

Connection Types Screw⇔Tube Connection Screw <=> Tube Connection Shape [Elbow (Barb)] Barb Elbow
Material [Stainless Steel] SUS316 Connection screw M
Applicable tube material (O.D./I.D.) Soft Nylon・Polyurethane (6/4) Gasket Material Nylon 66・GF30%
Made to Order Specifications N/A Screw Pitch(mm) -
